F5

Ultra Compact Funktion-One Sound

Overview

F5 is an ultra compact and extremely balanced loudspeaker, with a natural sound quality not typically found in loudspeakers of its size.

It produces a full range of frequencies from one voice coil, ensuring excellent coherency. These properties, in combination with its class leading vocal intelligibility, make it well suited for distributed public address systems, bars and restaurants, as well as domestic applications such as home theatre and desktop monitoring. Funktion-One’s range of compact bass loudspeakers can be partnered with the F5 for additional low frequency extension.

PERFORMANCE FEATURES

The F5 is an ultra compact loudspeaker with an extremely balanced sound

  • 1
    Bespoke wide range 5" driver
  • 2
    High sensitivity
  • 3
    Integrated passive filter for low frequency protection
  • 4
    Up to 8 units can be connected in parallel
  • 5
    Angled cabinet for desktop use
  • 6
    3/8" microphone stand mount
  • 7
    Optional yoke for stand or suspension
  • 8
    Optional 70/100V line transformer

Technical Specification

Driver 5”
Operating Band 160Hz - 13kHz
Sensitivity at 1m 97dB at 4V
Power (AES) 30W
Nominal Impedence 16Ω
USABLE BANDWIDTH (-3DB) 160Hz - 13kHz
Weight 2.7kg (5.9lbs)
Nominal Dispersion Conical
Connectors 2 x speakON NL4 or Phoenix
