ID48X Matrix Signal Processor
Enhanced audio performance
OVERVIEW
The third generation ID48X offers the same audio performance and remote control flexibility as the acclaimed D48X in a package ideally suited to installation applications.
With inputs and outputs switchable in channel pairs between analogue or AES/EBU the ID48X gives you the flexibility you need to integrate into your system. D-Net Ethernet based control software for PC, Mac and iPad enables control of all the devices on a network, plus the capability to store pre-set memories and configure systems offline. With enhanced audio performance thanks to the latest ESS AD/DA converter chipsets increasing the already impressive dynamic range and reducing THD+N figures, the ID48X offers even more than ever before.
DIMENSIONS
44mm high x 213mm x 382mm
- Analogue Inputs4 x e-balanced
- AES Inputs2 x 2 balanced
- Analogue Outputs8 x e-balanced
- AES4 x 2 e-balanced
- Frequency Response12Hz – 32kHz +0.2dB
- Latency0.427mS
- Power90-250VAC
- THD+N0.00029%
