Increased Headroom for Evo 2 Systems
Overview
Evo 2L is the mid-bass addition for the Evo 2, increasing headroom and enabling the full output capacity of the mid-high elements.
An intuitive coupling mechanism enables quick and safe attachment of an Evo 2L to the top or bottom of an Evo 2. Once connected, the assembly can be lifted by the Evo 2’s Butterfly Plate (BFP-2) as normal. Pairs of Evo 2 and Evo 2L can be flown together to form an extremely powerful system which is suitable for medium sized live music venues and clubs. A foam backed grille can be added for a more discreet appearance.
PERFORMANCE FEATURES
Increases the usable headroom of an Evo 2
- 1Safe and intuitive coupling mechanism
- 2Optional foam backed grille available for discreet appearance
- 3BFP-2 compatibility
- 4Optional grille
- 5Install version available (does not include coupling mechanism)
- 615mm Baltic birch ply construction
Technical Specification
Driver
OPERATING BAND
SENSITIVITY AT 1M
POWER (AES)
NOMINAL IMPEDANCE
Driver
12"
Operating Band
60/85Hz - 280Hz
Sensitivity at 1m
100dB at 2.8V
Power (AES)
600W
Nominal Impedence
8Ω
USABLE BANDWIDTH (-3DB)
WEIGHT
NOMINAL DISPERSION
CONNECTORS
USABLE BANDWIDTH (-3DB)
85Hz - 280Hz
Weight
21kg (46lbs)
Nominal Dispersion
N/A
Connectors
2 x Neutrik NL8 or NL4
