Wide Dispersion, Full Range, Point Source
![](https://images.prismic.io/funktion-one/6dd0ea8b-db3d-4fbd-bc36-22626c2ed050_Evo+X+Product+Page.png?auto=compress,format)
Overview
Evolution X is a significant development of the full range, fully horn loaded cabinet concept. Utilising the latest Funktion-One waveguide technology, Evolution X provides 90° dispersion and higher SPL.
Evolution X's advanced driver technology delivers market leading resolution and detail. It is an unbeatable choice for live venues, small club spaces and theatres. Capable of high SPL from a relatively compact enclosure, use as a pair for small live music events or as a four point small club system. Combine with the F Series or BR Range of bass loudspeakers for increased low frequency energy.
PERFORMANCE FEATURES
State of the art Funktion-One sound quality
- 1Single loudspeaker solution
- 2Wide 90° horizontal dispersion
- 3Full range, high SPL
- 4High efficiency/low energy consumption design
- 5Funktion-One designed drivers
- 6Wide bandwidth Funktion-One midrange (280Hz - 5kHz)
- 7New isophase diffraction HF waveguide technology
- 8Dedicated transport dolly (wheelboard)
![](https://images.prismic.io/funktion-one/d7badb01-c457-4633-8ee2-22d084e4b2bb_Funktion-One+Evo+X+Grid+2.jpg?auto=compress,format)
Technical Specification
Driver
OPERATING BAND
SENSITIVITY AT 1M
POWER (AES)
NOMINAL IMPEDANCE
Driver
15"
Operating Band
35/85Hz - 280Hz
Sensitivity at 1m
102dB at 2.8V
Power (AES)
400W
Nominal Impedence
8Ω
Driver
8"
Operating Band
280Hz - 5kHz
Sensitivity at 1m
107dB at 4V
Power (AES)
200W
Nominal Impedence
16Ω
Driver
1"
Operating Band
5kHz - 18kHz
Sensitivity at 1m
109dB at 4V
Power (AES)
100W
Nominal Impedence
16Ω
USABLE BANDWIDTH (-3DB)
WEIGHT
NOMINAL DISPERSION
CONNECTORS
USABLE BANDWIDTH (-3DB)
60Hz - 18kHz
Weight
47kg (103lbs) without wheelboard
Nominal Dispersion
90° Horizontal x 13° Vertical
Connectors
2 x Neutrik NL8
