Next Level Bass Loading and Driver Technology
Overview
V124 takes Funktion-One’s bass loading and driver technology to the next level.
This combination of mid-bass speed and impact with low-bass extension from a single enclosure makes the V124 the perfect bass partner for Vero and VX systems. The V124 delivers excellent transient response and extended depth to below 30Hz.
PERFORMANCE FEATURES
Excellent bass extension from a single enclosure
- 1New Funktion-One designed dual voice coil 24” driver
- 2FEA-optimised Neodymium magnet
- 318mm birch ply
- 4Integral handles
- 5Low centre of mass for easy handling
- 6Location feet and recesses for stacking
Technical Specification
Driver
OPERATING BAND
SENSITIVITY AT 1M
POWER (AES)
NOMINAL IMPEDANCE
Driver
24" dual voice coil
Operating Band
20Hz - 85Hz
Sensitivity at 1m
104dB at 2V
Power (AES)
2 x 750W
Nominal Impedence
2 x 8Ω
USABLE BANDWIDTH (-3DB)
WEIGHT
NOMINAL DISPERSION
CONNECTORS
USABLE BANDWIDTH (-3DB)
35Hz - 160Hz
Weight
103kg (227lbs)
Nominal Dispersion
Array dependent
Connectors
2 x Neutrik NL4
